Panel mount USB QC 3.0 and USB Type-C Car Charger, suitable for use with 12V or 24V systems.
The USB-A port provides 2.1A at 5V (QC3.0 standard) whilst the USB-C port provides from 3A at 5V (depending on the model), ensuring your devices will receive a fast charge.
This socket fits into a standard 29mm panel hole, secured from behind with a nut. We have a range of surface mounting pods available into which this socket can be fitted
Specifications
- Input voltage: 12V or 24V DC (6-30V DC)
- Output voltage: 5V DC
- Protection rating: IP65
- Illumination: Blue LED
- Over-voltage protection: Yes
- Over-current protection: Yes
- Panel cut-out diameter: 29mm
- Cable connection: 2 x 6.3mm male blade terminals
- Overall dims (inc. terminals): 65 (L) x 36mm (Dia.) mm
Wiring harness (x2) with fuse included.
